Skick: begagnad, Tillverkningsår: 2022, Fully integrated turning and tilting table with counter bearing Additional fixed table on the left for the first machining side X-travel of 1,530 mm High dynamics and speeds of 20,000 rpm Fully encapsulated work area, separate from the Tool magazine Good accessibility Easy to automate with pallets and robots X-axis travel 1.530 mm Y-axis travel 530 mm Z-axis travel 465 mm Rotary table diameter 5th axis 650 mm Number of tools 54 Spindle speed 20 000rpm Tool Holder HSK63 U-1530 MACHINE: Advanced build variant for highest performance level in U5 5-axis version Strokes X=1530mm, Y=530mm, Z=465mm Linear guidance in all three axes Required setup elements on the machine bed for adjustment Full cladding splash guard + working area light High Precision MILLING SPINDLE: Up to 20,000 rpm in fit-motor spindle With direct drive without belt Liquid cooling Tool mount on HSK63 spindle TOOL MAGAZINE: With 54 tool stations High-speed intelligent controller version With fast-running tool chain Separated from working area by pneumatic flap U-1530 FIXED TABLE: With T-slots for fixing workpieces and clamping devices 160mm top plate available for distance table/spindle for tall superstructures and use of tailstock DIRECT MEASURING SYSTEMS in X/Y/Z-Axis: For increased positioning accuracy and improved heat transfer Designed with Heidenhain scales and integrated in control Version with SIEMENS control with the following features: Attention: Siemens general conditions for software products are valid SIEMENS 840D control with features: New developed: SPINNER-SPIOS 24" Touch Control Panel for 10.4 applications Ultra-compact design with reduced panel footprint for premium ergonomics Multitouch layout, colorful flat panel display with Multi touch functionality Integrated Edge devices for full digitalization Easy to use and user interface 2-Axis Rotary Tilt Table D=650: High precision “S” design Made in Germany with direct measuring systems on both rotary axes Designed for demanding machining operations Equipped with high-power gear Rotary feed for automatic operations and pallet changer Equipped Features: Pre-tensioned high-performance brakes in B and C axis Designed for clamping during emergency stop High axis stiffness Increased accuracy in the tilting axis Heavy-Duty Table: Max load capacity 650 kg Tilting force and accuracy designed for serious machining Hydraulic Brake: For large rotary table in C-axis Increased rigidity during machining Counter-Balance Function in B-axis: Compensates tilting moment on the rotary table with workpiece force Enhanced stability during machining 6-Fold Rotary Feed: Inside the center of the C-axis 6-channel designed for media connection Max hydraulic pressure of 240 bar or additional exhaust ventilation connections High-pressure tank: 70 bar capacity with paper band filter for flushing, located centrally through the spindle, stand-alone next to the machine with additional coolant volume, including high-pressure pump and level monitoring. Additional blower: Air at headstock for cooling with air instead of liquid. Compressed air supply: Supplying via milling spindle, alternatively to coolant high-pressure through spindle. Hnolhcewkum Tocqljl Rinsing gun: Installed in the working area for cleaning. Preparation: For SPINNER-Blum Touch probe with IR receiver for wireless transmission. "Advanced Surface" For optimizing the machining surface. "Spline Interpolation" To shorten...

Skick: begagnad, Tillverkningsår: 2004, Mazatrol 640 MT Pro Control Type: Mazatrol 640 MT Pro Capto C6 Swing: 851 mm Turning Diameter: 760 mm Helhccswdw Hcsqlonl Center Distance: 1500 mm Bar Capacity: 88 mm X-Axis Movement: 630 mm Y-Axis Movement: 230 mm Z-Axis Movement: 1585 mm B-Axis Spindle Tilt: 225° CTS 15 Bar C-Axis Index Increment: 0.001° W-Axis Movement: 1050 mm Main Motor: 30 HP Sub Spindle Speed: 4,000 rpm Sub Spindle Motor (HP): 25/20 HP Live Tool Speed: 12,000 rpm ATC: 40 tools in magazine

Skick: begagnad, Tillverkningsår: 2007, Technical Specifications: Mazatrol Matrix X-Axis Movement: 630 mm Y-Axis Movement: 230 mm Z-Axis Movement: 1610 mm Max Turning Length: 1496 mm Max Turning Diameter: 660 mm Spindle Speed: 3000 rpm Helhccewdwvwoqljnl Number of Tools: 40 pcs, Revolver 9 pcs. Type of Tool Holder: Capto C6 Motor Power: 25 - 30 kW Conveyor: ConSep 2000-II 70 bar pump for coolant. Robotinterface Renishaw MP-10 Dimensions: Length: 5100 mm Width: 2900 mm Height: 2798 mm

Skick: begagnad, Tillverkningsår: 2007, GL-150F Gantry loader Max. turning Ø: 660mm X-Axis: 580mm Y-axis: 160mm Z-Axis: 1545mm B Axis: 270° Spindle bore: 65mm Subspindle bore: 65mm Subspindle power: 18.5kW Speed range: 5000Rpm Spindle power: 22kW ATC 40pcs Revolver 9pcs Hnelhccqjwdwm Nslol B-Axis Toolsystem:Capto C6 B-Axis Speedranges:12000Rpm Length: 5200mm Width: 2550mm Height: 2600mm

Skick: begagnad, Tillverkningsår: 2005, Mazak VC Nexus 510C Mazatrol 640M Nexus YOM: 2005 Hnolhccqswdwkhjlel Table: 1300 x 550 mm X: 1050 mm Y: 510 mm Z: 510 mm 12 000 Rpm/18,5 kW spindle: ISO-40 ATC: 30 positioner tool measure, CTS 15 bar Performance CNC optional package

Skick: begagnad, Tillverkningsår: 2004, Mazak Multiplex 6300 Hnslhccev Tvkaoqlsl Mazatrol 640T YOM: 2004-11 approximatly 20 pcs tools Mazak Flex-GL200F More info is coming

Skick: begagnad, Tillverkningsår: 2011, Mazak HC Nexus 6000-II Mazatrol Matrix Nexus Year: December 2011 Pallet Size: 500 mm x 500 mm Movement: - X: 800 mm - Y: 800 mm - Z: 800 mm Max Workpiece: Ø 900 mm x 1000 mm Max Table Load: 1000 kg Spindle Speed: 10,000 rpm (2 gears) Spindle Power: 30/37 kW Holhcjv Tvivscqlsnl Spindle Taper: CAT 50 Rapid Traverse X/Y/Z: 60 m/min Tool Magazine: 80

Skick: begagnad, Tillverkningsår: 2011, Mazak HC Nexus 5000-II Mazatrol Matrix Nexus Year: July 2011 Pallet Size: 500 x 500 mm Movement: - X: 730 mm - Y: 730 mm - Z: 740 mm Spindle Speed: 12,000 rpm Hnjlhccsv Tvh Seqlsl Tool Changer: 40 positions Chip Conveyor: Cromar

Skick: begagnad, - Capacity: - Maximum swing: 540mm Hnjlhccjv Rc A Roqlsl - Chuck size: 210 (8) mm (in.) - Maximum machining capacity: - Diameter: 540mm - Maximum machining length: 1018mm - Spindle: - Speed range: 35 – 4500 rpm - JIS A2-6 - Through-hole diameter: 61mm - Max. Bar material: 51mm - Motor output: - Continuous: 18.5/15 (25/20) kW (HP) - 30-minute rating: 22 (30) kW (HP) - Mill spindle speed: - Maximum speed: 6000 min^-1 - X-axis: 530mm - Y-axis: 140mm - Z-axis: 1065mm - Control: - CNC unit: Mazatrol Fusion 640MT

Skick: begagnad, Tillverkningsår: 2019, TSUGAMI B0386E-III Swiss type lathe The machine is in very good condition with Low hours. It was installed in a small company new in 2021-10 WORKING AREA Bar diameter Ø mm 8 – 38 Max part length mm 320 (Direct-driven rotating guide bushing) Max part length mm 70 (Without guide bushing) Max drilling diameter Ø mm 13 Max thread diameter M 12 Max chuck diameter for sub spindle Ø mm 38 Max drilling diameter for sub spindle Ø mm 12 Max thread diameter for sub spindle M 12 Max drilling diameter for driven tools Ø mm 10 Max thread diameter for driven tools M 8 Max diameter T-slot cutter (driven tool) Ø mm 45 CAPACITY Max spindle speed main spindle rpm 6000 Max spindle speed sub spindle rpm 7000 Max spindle speed rotating guide bushing rpm 6000 Max spindle speed tool spindle rpm 5000 Number of tool positions pcs 29 Tool size mm 16x16x125, 20x20x125 Rapid traverse speed m/min 32 (Z2, X2) 24 (X1, Y1, Z1, Y2) MOTORS Main spindle kW 11 / 7.5 Sub spindle kW 5.5 / 3.7 Driven tools kW 1.4 (1.0 for cross-drilling units front tool post) Y2 kW 0.5 X1, Y1, Z1, X2, Z2 kW 0.75 Coolant pump kW 0.4 Lubricating oil pump W 3 CONTROL SYSTEM FANUC 32i-B Controlled axes (including C-axes) pcs 8 X1, Z1, Y1, X2, Z2, Y2, C1, C2 LCD / MDI 10.4” color LCD OTHER Coolant tank L 190 Length x width x height mm 2240 x 1515 x 2050 Net weight kg 4950 Power requirement KVA 22.5 EQUIPMENT: Fanuc 32i-B control system with 8 controlled axes (X1, Z1, Y1, X2, Z2, Y2, C1, C2) Cross drilling unit with 4 spindles C-axis for main spindle and sub spindle Automatic programming software Abile Tool height compensation function Tool counter Screen for periodic maintenance Door lock Coolant level detector Spindle cooler Standard tools Retractable coolant nozzle Brake for the main spindle MACHINE PRICE: TSUGAMI B0386E-III (8 controlled axes) OPTIONS INCLUDED IN THE MACHINE PRICE: Hnelsv Ipuzohccqljl Tool set gauge O.D. Included Signal tower 3-step Included Work lighting LED Included Bar interface Included High-pressure pump (1.5 kW, 20 bar, 18 l/min) Included Rear drive unit (rear drive, 1.4 kW) Included Brake for sub spindle Included Direct-driven rotating guide bushing (Tsugami 2621-1234) Included Adapted for water-based cutting fluid (water type coolant specification) Included Oil blowing with M code (X-axis front 1, X-axis rear, Z2) Included Adapter for main spindle (Shaublin F37) and sub spindle (Shaublin F37) Automatic power off Included Air blowing for main spindle, sub spindle, and cross drilling unit 2 years Fanuc warranty (from shipment) Transformer, Operator manual, Compliance with European requirements including CE marking Drill set gauge I.D. (Long, Middle, Short) Detail ejector front with oil blowing (stroke 147, max work length 106 mm) Part conveyor with part separator (chute width 135, belt width 90) Rigid tapping also for rotating tools (cross drill, rear drive, back drive) 3 tool spindles for rear drive ER16, max 5000 rpm (tool spindle for rear drive) 4 tool spindles for back tool post (3282-Y041) 4 back adapters (dia 25 fixed tool) Guide bush adapter (Dunner CJ9) Guide-bushless kit incl stopper Chip conveyor (flat type) 10.4” color screen Included Minimum input increment (0.0005mm for X1 & X2, 0.001 mm for other axes) Included Linear interpolation Included Circular interpolation Included G04 Dwell (delay) 0-99999.99 Included Absolute/Incremental programming (X, Z, Y, C absolute / U, W, V and H incremental) ...

Skick: begagnad, Tillverkningsår: 2007, X Axis Travel: 558 mm Y Axis Travel: 635 mm Hnjlhcovu Srpocqlel Z Axis Travel: 558 mm Rapid Rate X Axis: 3550 mm/min Rapid Rate Y Axis: 3550 mm/min Rapid Rate Z Axis: 3550 mm/min Spindle Speed: 12,000 RPM Spindle Motor: 22.4 kW Spindle Taper: 40 CT Tool Changer: 40 ATC Pallet Size: 400 mm x 400 mm Weight: 11,115 kg HAAS CNC Control Coolant Thru Spindle 360 Deg. Indexing Table Indexable 4-axis Dual pallet changer

Skick: begagnad, Tillverkningsår: 2004, X-Axis 700 mm Y-Axis 360 mm Z-Axis 270 mm Table size Hnjlhccqoumrpzjlsl length 600 mm width 300 mm Number of tool pockets 21 Spindle taper BT-30 Max. spindle speed 10000 rpm Length x width x height 1828.8 × 1574.8 × 2209.8 Weight 1800.4 kg
